KHS KHS 6600
This item is currently not available.
Details
Mountain bikes are just that, a bike to take to off road into the mountains. These bikes typically have suspension forks and/or rear suspension. KHS makes Mountain bikes that give you a comfortable fit to help you be able to get and ride all day long.
| Small/15 | Medium/16 | Large/17.5 | X-Large/19 | |
|---|---|---|---|---|
| s/t c-t | 380/15 | 410/16.1 | 440/17.3 | 470/18.5 |
| h/t° | 65.5° | 65.5° | 65.5° | 65.5° |
| s/t° | 78.3° | 78.3° | 78.1° | 78.1° |
| t/t effectv | 553/21.8 | 575/22.6 | 601/23.7 | 627/24.7 |
| c/s | 440/17.3 | 440/17.3 | 440/17.3 | 440/17.3 |
| BB Height | 332/13.1 | 350/13.8 | 350/13.8 | 350/13.8 |
| s.o. | 752/29.6 | 776/30.6 | 786/30.9 | 786/30.9 |
| h/t L | 100/3.9 | 105/4.1 | 120/4.7 | 130/5.1 |
| Stack | 597/23.5 | 601/23.7 | 615/24.2 | 624/24.6 |
| Reach | 430/16.9 | 450/17.7 | 472/18.6 | 495/19.5 |
Specs
| Frame | MSD Full Carbon 4-Bar Horst Link, 29/650B+, 135mm, 1.5 Taper, 12 x 148 Boost Rear Axle, w/Replaceable Derailleur Hanger |
|---|---|
| Fork | FOX Float 36, 29 Std/27.5+ Evol Air, Rhythm, 150mm, Grip Sweep Adj., Ext Rebound Adj., 1-1/8~1.5 Taper, 15mm x 110 QR Boost |
| Rear Shock | FOX Float DPS, Performance, 3-Pos, Evol w/LV Eyelet |
| Rims | WTB ST=S:i35, M-XL:i29 TCS, Disc, Double Wall, 28H, Tubeless-Ready |
| Hubs |
Front: Shimano HB-MT410, CenterLock Disc, 15mm x 110mm, Boost Rear: Shimano FH-MT410-B Disc Cassette, 12 x 148mm, Boost |
| Spokes | 14/15G Double Butted Stainless, Black w/Aluminum Nipples, 28x28 |
| Tires | Kenda Regolith Pro, S:27.5 x 2.6”, M-XL:29 x 2.4”, 120TPI, Folding, Tubeless-Ready |
| Bottom Bracket | FSA MegaExo Outboard Cartridge Bearing |
| Crankset | FSA Gamma Pro, 2-pc., 30T Megatooth, Boost, PF92, S:170, M-XL:175 |
| Shifters | Shimano SLX, SL-M7100, 12s, Trigger, Right Only, I-Spec EV |
| Rear Derailleur | Shimano SLX, RD-M7100 |
| Cassette/Freewheel | Shimano CS-M6100, 10-51T, 12-Speed |
| Chain | Shimano CN-M6100 |
| Brakes | Shimano MT420 4-Piston Hydraulic Disc,180/160mm Rotors= RT64 CenterLock |
| Brake Levers | Shimano M4100, I-Spec EV |
| Handlebars | FSA Grid 35mm, 800mm x 20mm |
| Tape/Grips | Q2 Lock-on |
| Stem | FSA Grid 3D Forged, 35mm |
| Headset | FSA No. 57/52, Zero Stack, 1-1/8”~1.5 |
| Seatpost | Kind Shock Exa-Form KSP-900-i, Integra w/Remote, Travel Adjust, 31.6mm |
| Saddle | WTB High Tail, CrMo Rail |
| Pedals | Sold separately |
* Subject to change without notice.
